Modern Aluminium Casement Windows Slide And Swing SoundProof

KPD60A Series Sliding Window

1. Arc inner fan and line pressing design, enhance the three-dimensional sense of vision; 2. Add edge design to edge seal to improve air tightness and water tightness;

3. High rail or flat rail threshold can be selected;

4. Standard 6mm+12A+6mm insulating glass.

Product performance

Wind pressure level 8 4.5≤ P3 < 5.0

Air tightness level 8 Q1 ≤0.5

Water tightness grade 5 500≤△ P < 700

Sound insulation level 3 30≤ RW + CTR < 35 Heat insulation level 5 3.0 > K ≥2.5

Surface:
1. The principle of electrophoresis technology
The electrophoresis is basically the same as the traditional light and transparent electrophoresis. The anode electrophoresis is carried out under the action of direct current. With the action of the electric field, the coated particles with charge are moved to the coated workpiece, which precipitates the electrophoresis coating deposited on the surface of the aluminium profile, forming a layer of film. The difference lies in the different types of coatings and the slightly different devices.
The electrophoretic coating includes acrylic resin, melamine resin, pigments, solvents, neutralizing agents, additives and other ingredients. Through the application of thermal fixing in the viaduct layer in the particle, the shape of the micro-concave coating during the process of baking was basically unchanged in the baking process, and the appearance of the film was formed uniformly. The degree of extinction can be adjusted by the ratio of high gloss paint and low gloss paint.
For profile color, due to the transparency of coating, the color of the product depends on the electrolytic coloring. The color of the profile can also be added to color, white, ivory, green, red, ash, etc., by selecting the color aluminum profile required by adding color pulp. The surface quality is better than spray.
2. Excellent performance of products
high transparency and full measure, with special gloss and transparency, the coating has a high stereo effect, and the color of the substrate is obvious.
the high hardness, when the temperature of 180 ℃ baking 30 min, hardness can be up to 4 to 5 h.
good level of flow, strong paint film, and smooth film.
with strong binding force and penetration, the coating is all-pervasive, and the wet film and dry film have a strong binding force.
the performance is good, resistance to discoloration and corrosion when the baking temperature of 180 ℃ ~ 200 ℃ workpiece does not change color, lasting bright color products, corrosion effect is perfect.
the aver

1. 1 y Company Briefing
●Established in 1997, Yonglong Aluminium keeps improving
ourselves to accomplish our mission: “Quality is our Life”
●There are 1000 staff working in 30,000 Square metre factory area
in Leping Industrial Park Sanshui Foshan.
●Annual capacity is 50,000 MT, of which 60% export to more than
50 different countries in Europe, Africa, North & South America, and
Australia;

Please tell us the information below, and we will give the best suggestion to you !
1. Where you intend to use the aluminium doors?
2. If you have the estrusion drawing, send us and we develop the correspondence mold.
3. Which color you want or tell us the architectural style you like.
4. Purchase quantity. It will convenient us to give you the best price.
